Power Jack

Power Jack

DC barrel jack that powers the whole board from a 12V supply

Barrel-jack power input for the board. Plug in a 12V supply and the module feeds the board's 12V rail through an electronic fuse, so motors, servos and other high-power modules get real current. An on-board current monitor reports how much the board is drawing over I2C, and a status LED shows the rail state at a glance.

For ages 14 and up. Not a toy. Contains small parts: choking hazard. Keep away from children under 3. Adult supervision recommended.

Made by Atech ApS, Lille Strandstræde 6A, st. th., 1254 København K, Denmark.

Technical specifications

Interface
I2C (current monitor)
Voltage
12V DC input
Current
eFuse protected
Size
Single-width (1 slot, extends past the board edge)

Key features

  • Standard DC barrel jack input
  • Electronic fuse protects the board
  • Current monitoring over I2C
  • Status LED

Common applications

Motor and servo projects
Bench power without USB
Permanent installations
Power monitoring
