Servo bus driver for the SO-ARM100 and SO-ARM101 robot arms

Drives a six-axis SO-ARM100 or SO-ARM101 arm built from Feetech STS3215 smart servos. The servos daisy-chain on one half-duplex UART bus, so the whole arm needs a single port and one cable: the module carries the bus data line and feeds the servos from the board's 12V rail through a 3A fuse. Move the arm by hand, record the motion and play it back.

For ages 14 and up. Not a toy. Contains small parts: choking hazard. Keep away from children under 3. Adult supervision recommended.

Made by Atech ApS, Lille Strandstræde 6A, st. th., 1254 København K, Denmark.

Technical specifications

Interface
UART (half-duplex, 1 Mbps)
Voltage
12V servo supply, 3.3V logic
Current
Up to 3A (fused)
Size
Single-width (1 slot, extends past the board edge)

Key features

  • Daisy-chained Feetech STS3215 servo bus
  • One 3-pin servo connector for the whole arm
  • Servo power from the 12V rail, 3A fused
  • Record and replay motion

Common applications

Pick and place
Teaching by demonstration
Desk robots
Multi-axis motion
